Name: Hot sale 180W Splicing Curing Module Sale for UV Led Chip Curing
Brand: shenzhen yuanming co., ltd
SKU: YM-180W-6031
Availability: InStock

Product Details

Place of Origin: CHINA

Brand Name: YM

Certification: High-tech Enterprise Certificate

Model Number: YM-180W-6031

Payment & Shipping Terms

Minimum Order Quantity: 1 unit

Price: Negotiate

Packaging Details: Carton

Delivery Time: 7-10 work days

Payment Terms: T/T

Supply Ability: 100000

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                180W UV LED curing module, UV LED chip splicing module, UV light curing module with warranty


Product Name:	UV Light Module	Power:	180W
Module Size:	60mm31mm2.0mm	Luminous Size:	60mm*15mm
Voltage:	39-45V	Current:	3-4.5A
Application:	UV PRINTER,UV INK,UV CURING	Lifespan:	20000hrs
Material:	Aluminum Alloy

Product Name:	UV Light Module
Power:	180W
Module Size:	60mm31mm2.0mm
Luminous Size:	60mm*15mm
Voltage:	39-45V
Current:	3-4.5A
Application:	UV PRINTER,UV INK,UV CURING
Lifespan:	20000hrs
Material:	Aluminum Alloy

Hot sale 180W Splicing Curing Module Sale for UV Led Chip Curing

Product Advantages

1. Long life: the service life is more than 10 times that of the traditional lamp machine.

2. Cold light source, no heat radiation, the surface temperature of the illuminated product is low,

solving the traditional heat injury problem. Particularly suitable for LCD edge sealing, film printing, etc.

3. The heat is small, can solve the problem of large heat generation of traditional equipment.

4. Instant lighting, no need to preheat to instantly achieve 100% power UV output.

5. The service life is not affected by the number of opening and closing.


			Product Name
			YM-180W-6031 UV LED MODULE

			Power
			180W

			Color
			UV

			Number of lamp beads
			18 pcs

			Diode type
			6565 smd

			Lens Material of Diode
			Qquartz

			View Angle of the Lens
			60 degree

			Module size
			60mm*31mm*2.0mm

			Luminous Size
			60mm*15mm

			Wavelength
			365nm, 385nm, 395nm, 405nm

			Voltage
			39-45V

			Current
			3-4.5A

			Chip Material
			LG,Seoul,Epileds

			Encapsulation process
			High temperature quartz lens package module

			Module material
			2.0mm Copper substrate

			Lifespan (hours)
			20000 hours

			Warranty
			1 year

			Application
			Apply in various UV printing industries, painting,

			Place of Origin
			Shenzhen, Guangdong, China

FAQ

Q1. Are you a factory?

A:Yes! We are factory in Shenzhen. We have been producing UV LED products for six years.

Q2. What's the wavelength of the UV LED lamp?

A: The wavelength of UV LED lamp usually are 365-405nm.The wavelength for inkjet printer is

395nm, 385/395nm for printing machine, 365nm for UV glue.

Q3. What's your LED chip?

A: We use are Korea LG, Seoul, Taiwna Epileds about the LED chip brand

Q4. What's the materials of the lamp and lens?

A: The materials of lamp is Aluminum,and the lens are quartz.

Q5.What's the cooling way?

A: Most of UVLED are water cooling. We also have several hot selling air cooling UVLED, more air cooling UV LED are on the way.

Application of UV LED Module

1. advertising Printing

2. 3D printing

3. Bar code printing

4. PCB board protection

5. Lens UV glue bonding

6. touch screen protection

7. furniture Varnish Drying

8. Medical instrument

9. Precision optics

Hot sale 180W Splicing Curing Module Sale for UV Led Chip Curing 0

If you have other needs, please contact us to provide you with the best solution.

Umi@ymleduv.com , Thank you for your attention.
