Product Details
Place of Origin: CHINA
Brand Name: YM
Certification: High-tech Enterprise Certificate
Model Number: YM-48W-11015 UV LED Module
Payment & Shipping Terms
Minimum Order Quantity: Negotiate
Price: Negotiate
Packaging Details: Carton
Delivery Time: 7-10 work days
Payment Terms: T/T
Supply Ability: 100000
Product Name: |
YM-48W-11015 UV LED Module |
Power: |
48W |
Module Size: |
110mm*15mm*2.0mm |
Luminous Size: |
102mm*3.5mm |
Encapsulation Process: |
High Temperature Quartz Lens Package |
Voltage: |
27-30V |
Current: |
1-1.4A |
LED Chips: |
Optional(LG/Epileds/ Seoul) |
View Angle Of The Lens: |
60,120 Degree |
Warranty: |
1 Year |
Product Name: |
YM-48W-11015 UV LED Module |
Power: |
48W |
Module Size: |
110mm*15mm*2.0mm |
Luminous Size: |
102mm*3.5mm |
Encapsulation Process: |
High Temperature Quartz Lens Package |
Voltage: |
27-30V |
Current: |
1-1.4A |
LED Chips: |
Optional(LG/Epileds/ Seoul) |
View Angle Of The Lens: |
60,120 Degree |
Warranty: |
1 Year |
YM-48W-11015 Advantages
1. Features:Fast, flexible curing and drying
2. Cool Printing Environment: Enables to print on heat sensitive substrates, viz. thin slides, self-adhesive sheet,
stretch PVC materials, and more. Minimum heat resistance allows effective bi-directional calibration.
3.Low energy consumption, just 20% of the ordinary uv lamp
4: No mercury, No Ozone, eco-friendly
5: Cold light source, low temperature
6. Long life of the Machine: LED has a long life. Thus, they offer long term benefits without lamp down time or any other
consumable cost. Power Saving: Consumes low electricity. Thus, it saves power and offers cost effective solution.
7. Environmental Friendly: Doesn’t consist mercury (a non-disposable element) and ozone gas that can harm the environment.
|
Product Name |
YM-48W-11015 UV LED Module |
|
Power |
48W |
|
Color |
UV |
|
Number of lamp beads |
16 pcs |
|
Diode type |
3535 smd |
|
Lens Material of Diode |
Silica gel or quartz |
|
View Angle of the Lens |
60, 120 degree |
|
Module size |
110mm*15mm*2.0mm |
|
Luminous Size |
102mm*3.5mm |
|
Wavelength |
365nm/385nm/395nm/405nm |
|
Voltage |
27-30V |
|
Current |
1-1.4A |
|
Chip Material |
Epileds/LG/Seoul |
|
Encapsulation process |
High temperature quartz lens package |
|
Module material |
Aluminum plate |
|
Lifespan (hours) |
15000 |
|
Warranty |
1 year |
|
Application |
Apply in various UV printing industries, painting, |
|
Place of Origin |
Shenzhen, Guangdong, China |
Q1. Can all the products be customized?
A1: We are the factory of making UV lamp,UV accessories. All the our products can be made by the details you provide.
Q2. What is the outer package of the product?
A2: carton packing or wooden packing.
Q3. Processing cycle?
A3: Some of products we have in stock. Usually need about 3-15days to maked.
Q4: Do all of current UV chemicals work well with UV LED?
A4: No, The chemical must be specifically to take advantage of the narrow Wavelength, please ask for your supplier for the best wavelength, and then we can customized the most suitable and high-efficiency wavelength for you.
Q5: How to get the best solution with right price?
A5: There are some important information we need to know before offering:
1,What do you use it for? (such as, it will be used for drying silk-screen printing )
2.Which wavelength do you need or what UV chemical do you want to cure? (It depends on your UV chemical, such as 365/375/385/395/405nm and so on.)
3.What size of emitting window do you need?(It depends on your product’s size or curing method)
4.How much peak irradiance do you need?(It depends on your UV chemical and your max producing speed.)
5.If any spec of common set can't meet your requirement, don't worry! CUSTOMIZED solutions are available.
